AQDB Sport Inflatable Boat - Navy Blue
Inflatable Boats AQDB-AKB

Sport Inflatable Boat (Aluminum Floor)

Versatile sport inflatable boat with rigid aluminum floor for excellent performance and durability.

sport-boat aluminum-floor fishing outboard multi-chamber
Models AQDB 7'7" to 18'1" (16 models)
Floor AKB interlocking aluminum slat system
Tube material PVC 0.9mm (1100 dtex)
Air chambers 3+1 to 9+1
Max load 610kg
Max power 15 HP (AQDB-18'1")
Spezifikationen
Inflation pressure 0.25-0.3 bar
Max occupants 13 persons (AQDB-18'1")
TLDR

Ein leichtes Sport-Schlauchboot mit rutschfestem Bodenplattensystem aus Aluminiumlegierung. Der starre Boden bietet eine ebene Standfläche, verbessert die Gleitfahrt und schützt den Rumpfboden vor Abrieb. Einfach zu montieren und für den Transport zu demontieren.

  • Freizeitbootfahrer, Angler, Vermieter und Nutzer, die ein tragbares Schlauchboot mit der Leistung eines starren Bodens brauchen.
  • Use cases:

The Aquafarer AQDB series is a complete inflatable boat line for the global B2B market, built around a multi-chamber safety design and a choice of floor systems. The AKB aluminum-floor configuration delivers the flat, rigid standing surface serious boaters expect from a hard-floor boat — with the packability of an inflatable.

Multi-Chamber Safety Design

Every AQDB model is equipped with 3+1, 4+1, 5+1, 8+1, or 9+1 independent air chambers. Because the chambers are isolated from each other, the boat keeps sufficient buoyancy even if a single chamber leaks — a level of redundancy many competitors do not offer at this price point.

Rigid Aluminum Floor (AKB)

The AKB floor is an interlocking slat system machined from aviation-grade aluminum. The panels lock into the inflatable keel and side tubes, transferring thrust from the outboard evenly across the hull for efficient planing. The anodized finish resists corrosion, and individual slats can be replaced without replacing the whole floor.

0.9mm PVC Construction

Tubes are built from 0.9mm PVC on 1100 dtex high-density polyester — thicker than the 0.7mm fabric used by many competing brands. The material resists abrasion, UV, and repeated inflation cycles, giving a service life suited to commercial use.

Size Range

The line covers 12 sizes from 7’7” to 18’1” (16 models), from compact two-person tenders to 13-person workhorses rated to 610kg and 15 HP. Optional extras include life vests, electric pumps, carbon-steel anchors, seat-board packs, bow bags, simple trailers, and boat covers — seven optional accessories that lock in order value per unit.

Ideal For

Recreational boaters, anglers, rental operators, and utility users who need a portable inflatable boat with rigid floor performance. The aluminum floor is more affordable than drop-stitch, simpler to repair, and available across a wide size range for fleet customization.

Choosing Your Model

Smaller AQDB models (7’7” to 10’) suit solo angling, tender duty, and compact trailers. Mid-size models (11’ to 14’) are the sweet spot for families and rental fleets, combining room for several passengers with outboard power in the 6-10 HP range. The largest models (15’ to 18’1”) deliver genuine workboat capacity — up to 13 passengers, 610kg of load, and 15 HP — for commercial, utility, and rescue roles.

Assembly & Transport

The AKB floor breaks down into individual slats that stow inside the boat bag. Two adults can assemble or disassemble the complete boat in under ten minutes: lay out the tubes, inflate to 0.25-0.3 bar, drop in the slats, lock the side tubes, and attach the transom. The packed boat fits in a standard car trunk or on a roof rack.

Care & Maintenance

Rinse the boat and floor with fresh water after use, especially in saltwater. Keep the aluminum slats dry before storage to prevent oxidation, and check the interlocking edges for burrs after rough landings. Inflate tubes only to the rated pressure — overinflation stresses the seams — and store the boat partially deflated, away from direct sunlight.

Das Problem

Schlauchboote mit weichem Boden haben nicht die Steifigkeit, die für Gleitleistung und Stehkomfort nötig ist. Nutzer brauchen einen Boden, der für den Außenbordbetrieb steif genug und dennoch abnehmbar für den tragbaren Transport ist.

Product Definition

Who is it for?

Ein leichtes Sport-Schlauchboot mit rutschfestem Bodenplattensystem aus Aluminiumlegierung. Der starre Boden bietet eine ebene Standfläche, verbessert die Gleitfahrt und schützt den Rumpfboden vor Abrieb. Einfach zu montieren und für den Transport zu demontieren.

Designed for

Freizeitbootfahrer, Angler, Vermieter und Nutzer, die ein tragbares Schlauchboot mit der Leistung eines starren Bodens brauchen.

Anwendungsfälle

Könnensstufe

intermediate

Vergleich

Wie es abschneidet

Im Vergleich zu SIBs mit Drop-Stitch-Boden ist der Aluminiumboden schwerer, aber steifer und günstiger. Er bietet eine ebenere Standfläche als aufblasbare Böden, braucht aber etwas länger beim Aufbau. Unempfindlicher gegen spitze Gegenstände als Drop-Stitch-Böden.

FAQ

Spezifikationen

Spezifikationen

Models AQDB 7'7" to 18'1" (16 models)
Floor AKB interlocking aluminum slat system
Tube material PVC 0.9mm (1100 dtex)
Air chambers 3+1 to 9+1
Max load 610kg
Max power 15 HP (AQDB-18'1")
Inflation pressure 0.25-0.3 bar
Max occupants 13 persons (AQDB-18'1")
Spezifikationen

Spezifikationen

models
8' to 14' lengths available
floor
Interlocking aluminum slat panels
tube material
PVC military-grade (1100 dtex)
air chambers
3+1
max power
3-25 HP depending on size
setup time
10-15 minutes
Compliance

Certifications & Compliance

Certifications

CE (EN 6185-1:2018) Certified by TÜV Rheinland
ISO 9001:2015 Certified by SGS
UKCA Certified by Intertek

Material Compliance

REACH (EU)
RoHS (EU)
California Prop 65

Testing & Warranty

ASTM D751 (Tensile/Seam)
ASTM G154 (UV Aging)
ISO 4646 (Cold Crack)
Warranty

2 years against manufacturing defects

CE Certified
Independently tested to EU safety standards — TÜV Rheinland.
ISO 9001:2015
Quality management system certified by SGS since 2022.
Tested to Standard
Every unit pressure tested at 1.5x rated PSI for 24 hours.
2-Year Warranty
Backed by comprehensive manufacturer warranty. 99.3% defect-free.
REACH & RoHS
All materials comply with EU chemical and environmental regulations.
BSCI Certified
Social compliance audit verified for ethical manufacturing.
